Pylon UF5000 5.12kWh 51.2V Li-ion battery (excl. brackets)
Pylon UF5000 5.12kWh 51.2V Li-ion battery (excl. brackets)
Regular price
R 17,900.00 ZAR
Regular price
Sale price
R 17,900.00 ZAR
Unit price
/
per
Couldn't load pickup availability
The UF5000 is a 51.2V, 5.12kWh lithium ion battery with incredible features to provide a competitive edge in the market.
Features:
- Modular design for ease of expansion.
- 95% DoD allowing higher usable capacity of 4.864kWh.
- 1C rated capable of discharging at 5.12kW.
- Parallel Capability of up to 20 units allowing installation of up to 102.4kWh capacity.
- Intelligent BMS protecting battery cells.
- 6000 cycles.
- RS485 and CAN compatible.
- Comes with a 10-year battery warranty.
The PYLON-UF5000 battery is not compatible with the PYLON-UP5000.
This product must be installed by a qualified electrician/technician. All installations must adhere to local wiring regulations and standards. SegenSolar will not be held liable for any product malfunctions as a result of incorrectly installed systems.
.
Technical Data:
Warranty: 10 Years
Weight: 42kg
Battery Type:Lithium Ion
Nominal Energy: 5.12KWh
Depth of discharge: 95%
Voltage: 51.2V
Continuous Discharge Rate (Normal Use): 5120W
Surge Discharge Rate (15 Seconds): 6195W
Maximum Charge Rate (5 Minutes): 5376W
